Uline Pallet Truck - Low Profile/4-Way Access, 48 x 33"

Slides easily under floor scales, machinery, wooden crates and other low profile equipment.
  • Slides into openings only 2" high. Can access 4-way pallets.
  • 3-position hand control - Raise, lower, neutral.
  • 2" lowered and 5.6" raised height.
  • 6" polyurethane steering wheels. 2" steel fork wheels.
  • 210° steering arc.
  • View video.

    Open-Bottom Pallet
MODEL
NO.
DESCRIPTION FORK SIZE
L x W
LOAD
CAPACITY
WT.
(LBS.)
PRICE EACH ADD TO
CART
1 3+
H-1781 Low Profile/4 Way 48 x 33" 3,300 lbs. 212 $682 $644 Unavailable
Until August
SHIPS ASSEMBLED VIA MOTOR FREIGHT
No preorders accepted.
DIMENSIONS:
  • Overall: 61 x 47 1/2" (L x H)
  • Forks:
    • Width: 6 1/4"
    • Thickness: 1 1/2"
    • Distance Between Forks (Inside): 20 1/2"
TEMPERATURE:
  • Hydraulic fluid may not function properly below -5° C (23° F).
INCLUDES:
  • Extra 3" Rod to lock hydraulics to change pump or handle.
REPLACEMENT WHEELS:
  • 6" Polyurethane Steering Wheel: H-1365-8
  • 2" Steel Fork Wheel with Bearings: H-1365-WHKIT
SPECIFICATIONSMETRICIMPERIAL
FORK LENGTH x WIDTH122 x 84 cm48 x 33"
LOAD CAPACITY1497 Kg3,300 lbs.
WEIGHT96 Kg212 lbs.
ACCESSORIES:PARTS:
  • H-1043-B113 Pull Pole Assembly for Uline Pallet Truck
  • H-1043-SHC Pump Handle for Uline Pallet Truck
  • H-1043PUMP Pump Assembly for Uline Pallet Truck
  • H-1483-B29 Shaft for Uline Industrial Pallet Truck
  • H-5630 Uline Low Profile Pallet Truck Polyurethane Steering Wheel - 6"
  • H-5631 1 3/8" Spring Pin for Uline Pallet Truck
  • H-5632 Uline Pallet Truck 1 1/4" Spring Pin
  • H-6017 Steering Wheel Hardware for Uline Pallet Truck
